38 ATR171 - User manual
5. s. m .
5 Samples Mean
6. s . m .
6 Samples Mean
7. s . m .
7 Samples Mean
8. s . m .
8 Samples Mean
9. s. m .
9 Samples Mean
10.s . m .
10 Samples Mean (Default)
11 . s . m .
11 Samples Mean
12. s . m .
12 Samples Mean
13.s . m .
13 Samples Mean
14.s . m .
14 Samples Mean
15.s . m .
15 Samples Mean
68
c. frn .
Conversion Frequency
Sampling frequency of digital / analogue converter.
NB: Increasing the conversion speed will slow down reading stability (example:
for fast transients, as the pressure, it is advisable to increase sampling frequency)
242H.
242 Hz (Maximum speed conversion)
123H.
123 Hz
62 H.
62 Hz
62 H.
50 Hz
39 H.
39 Hz
33.2H.
33.2 Hz
19.6H.
19.6 Hz
1 6 .7H .
16.7 Hz (Default) Ideal for filtering noises 50 / 60 Hz
12.5H.
12.5 Hz
10 H.
10 Hz
8.33H.
8.33 Hz
6.25H.
6.25 Hz
4 .1 7 H .
4.17 Hz (Minimum speed conversion)
69
u . fLt.
Visualization Filter
Slow down the update of process value visualized on display, to simplify reading
di s .
Disabled (maximum speed of display update)
p tcH
Pitchfork filter (First order filter with pitchfork) > Default.
fi . o r.
First order
f.or.p.
First order with pitchfork
2. s . m .
2 Samples Mean
3. s. m .
3 Samples Mean
4. s. m .
4 Samples Mean
5. s. m .
5 Samples Mean
6. s . m .
6 Samples Mean
7. s . m .
7 Samples Mean)
8. s . m .
8 Samples Mean)
9. s. m .
9 Samples Mean
10.s . m .
10 Samples Mean (Maximum slow down of display update)
