User manual - ATR171 41
79
re t r.
Retransmission
Retransmission for output 0..10 V or 0/4..20 mA. Parameters 81 and 82 defines
upper/lower limit of scale
di s .
Disabled (Default)
c.spu .
Command Setpoint
p r o .1
Process 1
pro .2
Process 2
mean
Processes Mean
di f f.
Processes Difference
abs.d.
Processes Difference as absolute value
80
re.ty.
Retransmission Type
Select retransmission type
0 -1 0
0..10 Volt (Default)
0-20
0..20 mA
4-20
4..20 mA
81
Lo .L. r.
Lower Limit Retransmission
Lower limit analogue output range
-999..9999 digit
12
(degrees if temperature), Default: 0.
82
up.L.r.
Upper Limit Retransmission
Upper limit analogue output range
-999..9999 digit
12
(degrees if temperature), Default: 1000.
83
bd. rt.
Baud Rate
Selects baudrate for serial communication
4.8 k
4800 bit/s
9.6 k
9600 bit/s
19.2k
19200 bit/s (Default)
28.8k
28800 bit/s
39.4 k
39400 bit/s
57.6k
57600 bit/s
11 5 . 2
115200 bit/s
84
sL. a d .
Slave Address
Selects slave address for serial communication
1 – 254. Default: 254
85
se. d e.
Serial Delay
Selects serial delay
0 – 100 milliseconds. Default: 20
12
The display of the decimal point depends on the setting of parameter
s e n .1
and
d. p. 1
or
sen.2
and
d . p. 2.
for only ATR171-23ABC-T.
