40 ATR171 - User manual
74
faGr
Falling Gradient
Falling gradient for pre-programmed cyle. In model ATR171-23ABC-T, this
parameter is visible only if dip-switches are configured for serial communication
(AI2 desabled).
0 Disabled.
1..9999 Digit/hour
12
(degrees/hour with decimal visualization if temperature),
Default: 0.
75
m a . ti .
Maintenance Time
Holding time for pre-programmed cycle. In model ATR171-23ABC-T, this
parameter is visible only if dip-switches are configured for serial communication
(AI2 desabled).
00.00-24.00 hh.mm, Default: 00.00
76
u.m.c.p.
User Menu Cycle Programmed
Allows to modify rise gradient, falling and maintenance time from user menu,
when pre-programmed cycle is selected. To start modification of parameters
press FNC key. In model ATR171-23ABC-T, this parameter is visible only if
dip-switches are configured for serial communication (AI2 desabled).
di s .
Disabled (Default)
ri . G r .
Rising Gradient
m a . ti .
Maintenance Time
r.G.m.t.
Rising Gradient and Maintenance Time
faGr
Falling Gradient
r.F. G. r.
Rising and Falling Gradient
f.G.m.t.
Falling Gradient and Maintenance Time
a LL
All
77
ui . d .2
Visualization Display 2
Set visualization on display 2
c.spu .
Command Setpoint (Default)
p r o .1
Process 1
pro .2
Process 2
mean
Processes mean
di f f.
Processes difference
abs.d.
Processes difference as absolute value
78
ui . ty .
Visualization Type
Set visualization type on display
std.
Display 1 process + Display 2 as
ui . d .2
(Default)
d.2.Hi.
Display 1 process + Display 2 as
ui . d .2
hidden after 3 sec.
suap
Display 1 as
ui . d .2
+ Display 2 process
s.d.2.H.
Display 1 as
ui . d .2
+ Display 2 process hidden after 3 sec.
