User manual - ATR227 - 27
12 Conguration EASY-UP
To simplify the setting of parameters and the integration of the dierent components
involved in the control system, Pixsys introduces the EASY-UP coding which allows to
set sensors and/or command outputs in one single step.
By means of the code listed in the data sheet enclosed to the sensor or actuator (SSR,
motorized valve, etc.) the EASY-UP coding will set the relevant main parameters on
the controllers (ex. selection of PT100 on parameter “SEN” and the corresponding
measuring range on parameters “Lower and Upper limits of the setpoint”).
Dierent codes may be entered on the controllers in sequence to congure inputs,
control output or retransmission of signal.
2200 PT100 (-100..500°C); ON/OFF with hysteresis 1°C on Q1; absolute Alarm 1 on Q2
2201
PT100 (-100..500°C); ON/OFF with hysteresis 1°C on SSR; absolute Alarm 1 on Q1
2204
PT1000 (-100..250°C); ON/OFF with hysteresis 1°C on Q1; absolute Alarm 1 on Q2
2205
PT1000 (-100..250°C); ON/OFF with hysteresis 1°C on SSR; absolute Alarm 1 on Q1
2250 PT100 (-100..500°C); PID automatic tune on Q1; absolute Alarm 1 on Q2
2251 PT100 (-100..500°C); PID automatic tune on SSR; absolute Alarm 1 on Q1
2300 TC J (-100..600°C); ON/OFF with hysteresis 1°C on Q1; absolute Alarm 1 on Q2
2301 TC J (-100..600°C); PID automatic tune on SSR; absolute Alarm 1 on Q1
2400 TC K (-100..850°C); ON/OFF with hysteresis 1°C on Q1; absolute Alarm 1 on Q2
2401 TC K (-100..850°C); PID automatic tune on SSR; absolute Alarm 1 on Q1
13 Summary of Conguration parameters
Date: Model ATR227
Installer System:
Notes:
1
SEN. Sensor (Password 1234)
2
d . P. Decimal Point (Password 1234)
3
d eG r. Degree (Password 1234)
4
Lo .L.i . Lower Linear Input (Password 1234)
5
u p.L.i . Upper Linear Input (Password 1234)
6
c.out Command Output (Password 1234)
7
Act. t. Action type (Password 1234)
8
P.i . d . PID (Password 1234)
9
Lo .L.S. Lower Limit Setpoint (Password 1234)
10
u p.L.S. Upper Limit Setpoint (Password 1234)
11
o . cAL. Oset Calibration (Password 5678)
12
G. caL. Gain Calibration (Password 5678)
To Next Page
