16 - ATR227 - User manual
9 Table of Conguration Parameters
The parameters list below can be entered by passwords 1234 (for standard) and 5678
(for advanced). Enter password 1357 to access the complete list
1 SEN. Sensor (Password 1234)
Analogue input conguration
Tc.K Tc-K (Default) -260 °C..1360 °C
Tc.s Tc-S -40 °C..1760 °C
Tc.r Tc-R -40 °C..1760 °C
Tc.j Tc-J -200 °C..1200 °C
Tc.t Tc-T -260 °C..400 °C
Tc.E Tc-E -260 °C..980 °C
Tc.n Tc-N -260 °C..1280 °C
Tc.b Tc-B 100 °C..1820 °C
Pt Pt100 -100 °C..600 °C
Pt1 Pt100 -100 °C..140 °C
ni Ni100 -60 °C..180 °C
ntc NTC10K -40 °C..125 °C
Ptc PTC1K -50 °C..150 °C
Pts Pt500 -100 °C..600 °C
Pt1k Pt1000 -100 °C..600 °C
0-10 0..10 V
0-20 0..20 mA
4-20 4..20 mA
0-60 0..60 mV
Pot.1 Potenziometri no a 6 kOhm
Pot.2 Potenziometri no a 150 kOhm
2 d . P. Decimal Point (Password 1234)
Select number of displayed decimal points
0 No displayed decimal Default
0.0 1 decimal
0.00 2 decimals
0.000 3 decimals
3 d e G r. Degree (Password 1234)
Select degree type
c Celsius (Default)
f Fahrenheit
