Pixsys TCT101-1ABC User Manual

16 - TCT101-1ABC - User manual
9.b Backup memory configuration
2
p.o.me.
Power-off memory
Memory after switch-off
di s . Disabled. Default.
o . ti m . Memory stores only value of Timer
aLL Memory stores value of Timer and START/
STOP status
9.c Inputs configuration
3
H . i n .1
Hardware Input 1
Configuration Input 1
n pn NPN
pn p PNP. Default.
ttL TTL
4
H.i n .2
Hardware Input 2
Configuration Input 2
n pn NPN
pn p PNP. Default.
ttL TTL
5
H.i n .3
Hardware Input 3
Configuration Input 3
pn p PNP. Default.
ttL TTL
Pot. Potentiometer (5..10 Kohm)
6
a.in.1
Active State Input 1
Activate Input 1
H .Lev . High level
L. Lev . Low level
Ri si . Rising edge. Default.

Pixsys TCT101-1ABC Specifications

General

Brand	Pixsys
Model	TCT101-1ABC
Category	Timer
Language	English
