User manual - TCT101-1ABC - 17
7
a.in.2
Active State Input 2
Activate Input 2
H .Lev . High level
L. Lev . Low level
Ri si . Rising edge. Default.
8
a.in.3
Active State Input 3
Activate Input 3
H .Lev . High level
L. Lev . Low level
Ri si . Rising edge. Default.
9
F. i n .1
Function Input 1
Function of Input 1
di s . Disabled
st.st Start / Stop
3 p. 25
. Default.
st .s r. Start / Stop-Reset
4 p. 25
rs .st Reset-Start / Stop
5 p. 25
r.s.s. Reset / Start / Stop
6 p. 25
10
F.i n . 2
Function Input 2
Function of Input 2
di s . Disabled. Default.
res . Reset
11
F.i n . 3
Function Input 3
Function of Input 3
di s . Disabled
w ai t Wait (stop the counting)
HoLd Hold (Hold value on display but counting goes
on). Default.
S et1 Modify SET1 by potentiometer
Set2 Modify SET2 by potentiometer
