PizzaGroup PYRALIS - Page 183

183
Figure 1: PYRALIS OVEN M6 – PYRALIS OVEN D6
Pos.
Code
Description
Q.ty
1
A86EL46004
CABLE GLAND OBO PG21 GREY
1
2
A86EL46010
GUIDE BUSH
2
3
A86EL47003
LOCK NOT OBO PG21 GREY
1
4
A86EL48001
EQUIPOTENTIAL FITTING
1
10
A87RZ65055
UPPER HEATING ELEMENT 600W 230V
6
11
A87RZ65056
LOWER HEATING ELEMENT 580W 230V
9
12
A88SO86002
PROBE T4JA44VH25IPD-f S/M 600°C
2
16
A90MA65016
BLACK CHIMNEY CLOSING KNOB
1
19
A94NC00004
TREATED FIBREGLASS BRAID - SQUARE SECTION 15X12 mm
0,8mt. x 1pcs.
20
A95FA65004
PERFORATED REFRACTORY BRICK 1050X350X22 Mod. 6÷9÷12÷18
2
27
S66CU64002
COVER PYRALIS OVEN 6-12 2022
1
29
S40LT64051
LEFT PANEL
1
S40LT64061
RIGHT PANEL
1
30
S40PS64027
BACK PANNEL PYRALIS 4-6 2022
1
41
S52CO64005
FIBREGLASS BRAID SUPPORT PYRALIS OVEN 4-8-6-12 2019
1
52
A87IL73009
LAMP HOLDER 80X65 G4 12V 20W
1
53
LAMP 12V 20W G4
1
54
RETTANGULAR LAMP GLASS
1
A
Detail A
MECHANICAL CONTROL PANEL SINGLE CHAMBER
1
DIGITAL CONTROL PANEL SINGLE CHAMBER
1
B
S35FN64061
COMPLETE DOOR PYRALIS OVEN 4-6-8-12 2022
1
S35FN64067
COMPLETE DOOR PYRALIS UP OVEN 4-6-8-12 2022
1
C
S72FN64019
ELECTRICAL SYSTEM PYRALIS OVEN 2022
1
Figure 1: PYRALIS OVEN M12 – PYRALIS OVEN D12
Pos.
Code
Description
Q.ty
1
A86EL46004
CABLE GLAND OBO PG21 GREY
1
2
A86EL46010
GUIDE BUSH
2
3
A86EL47003
LOCK NOT OBO PG21 GREY
1
4
A86EL48001
EQUIPOTENTIAL FITTING
1
10
A87RZ65055
UPPER HEATING ELEMENT 600W 230V
12
11
A87RZ65056
LOWER HEATING ELEMENT 580W 230V
18
12
A88SO86002
PROBE T4JA44VH25IPD-f S/M 600°C
4
16
A90MA65016
BLACK CHIMNEY CLOSING KNOB
2
19
A94NC00004
TREATED FIBREGLASS BRAID - SQUARE SECTION 15X12 mm
0,8mt. x 2pcs.
20
A95FA65004
PERFORATED REFRACTORY BRICK 1050X350X22 Mod. 6÷9÷12÷18
4
27
S66CU64002
COVER PYRALIS OVEN 6-12 2022
1
29
S40LT64055
LEFT PANEL
1
S40LT64065
RIGHT PANEL
1
30
S40PS64031
BACK PANNEL PYRALIS 8-12 2019
1
41
S52CO64005
FIBREGLASS BRAID SUPPORT PYRALIS OVEN 4-8-6-12 2019
2
52
A87IL73009
LAMP HOLDER 80X65 G4 12V 20W
2
53
LAMP 12V 20W G4
2
54
RETTANGULAR LAMP GLASS
2
A
Detail A
MECHANICAL CONTROL PANEL DOUBLE CHAMBER
1
DIGITAL CONTROL PANEL DOUBLE CHAMBER
1
B
S35FN64061
COMPLETE DOOR PYRALIS OVEN 4-6-8-12 2022
2
S35FN64067
COMPLETE DOOR PYRALIS UP OVEN 4-6-8-12 2022
2
C
S72FN64019
ELECTRICAL SYSTEM PYRALIS OVEN 2022
2
