RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 19
020-1332-00I
IP V4. GATE WAY Default Gateway 1206 =? ACTIVE
STATIC
MASTER
DHCP
[None = ACTIVE (for reads
only)]
[None = STATIC (for writes
only)]
String IP V4. GATE WAY( DHC P)?
IPV4.GATEWAY(DHCP):"10.15.0.1"
IPV4.GATEWAY(1)=192.168.0.1
IPV4.GATEWAY(1):"192.168.0.1"
Gets the master equipment specified
network gateway.
Sets the master static network gateway.
Modifiers MASTER and STATIC are
equivalent.
No 2.0
8.0
1
Yes Yes
IPV4.NETMASK Subnet Mask 1205 =? ACTIVE
STATIC
MASTER
DHCP
[None = ACTIVE (for reads
only)]
[None = STATIC (for writes
only)]
String IPV4.NETMASK(2)?
IPV4.NETMASK(0):"255.255.254.0"
IPV4.NETMASK(STATIC)=255.255.255.
254
IPV4.NETMASK(STATIC):"255.255.255.
254"
Gets the master equipment specified
subnet.
Sets the master static subnet. Modifiers
MASTER and STATIC are equivalent.
No 2.0
8.0
1
Yes Yes
IR.CODE Remote Code 1210 =?+- 0-65535 IR.CODE=12345
IR.CODE:12345
Gets / sets remote code to work with
different remotes.
No 1.x Yes Yes
IR.LOCK Remote Lock 1202 =?+- 0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
IR.LOCK=ENABLE
IR.LOCK:ENABLE
Toggles the equipment from responding to
commands sent by a remote.
No 1.x Yes Yes
KEY.LOCK Front Keypad
Lock
1201 =?+- 0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
KEY.LOCK=DISABLE
KEY.LOCK:DISABLE
Toggles the equipment from responding to
commands from the keypad.
No 2.0 Ye s No
MATRIX.LAYOUT.
COLUMNS
Matrix Array
Columns
600 ? Integer MATRIX.LAYOUT.COLUMNS?
MATRIX.LAYOUT.COLUMNS:6
Returns the number of columns in the
configured wall.
No 4.0 Yes Yes
MATRIX.LAYOUT.
PA NEL
Array Panel ID 602 ? Column# and Row# Integer MATRIX.LAYOUT.PANEL(1 3)?
MATRIX.LAYOUT.PANEL(1 3):7
Returns the panel ID number for the
specified column/row coordinate in a
configured wall.
No 4.0 Ye s Yes
MATRIX.LAYOUT.
ROWS
Matrix Array
Rows
601 ? Integer MATRIX.LAYOUT.ROWS?
MATRIX.LAYOUT.ROWS:4
Returns the number of rows in the
configured wall.
No 4.0 Yes Yes
MENU.PANEL OSD Panel
Display
1311 =? Integer MENU.PANEL?
MENU.PANEL:4
Gets / sets the panel ID on which the main
OSD is displayed.
No 2.0 No No
MODEL.NAME Component
Model
2306 ? PS#
VC#
PN#
PSW#
String MODEL.NAME?
MODEL.NAME:"RPS220-3"
MODEL.NAME(PN3)?
MODEL.NAME(PN3):"MX55U"
Returns the directly connected equipment
model name without modifier. Returns the
specified equipment’s model name with
modifier.
Yes 1. x
4.0
1
10.0
1
Yes No
Command Description
Numeric Command Code
Operators
Modifiers Operands Example Notes
Standalone Component Command
Firmware Version Active
Functional in Fast Start Standby
Functional in Low Power Standby
