Planar RPS - Page 20

RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 20
020-1332-00I
NETWORK.
CONFIG.
MODIFIED
Network Change 1216 ? 0=DISABLE=OFF=NO=|
FALSE
1=ENABLE=ON=YES=
TRUE
NETWORK.CONFIG.MODIFIED?
NETWORK.CONFIG.MODIFIED:
TRUE
Returns whether the system network
configuration has changed. If yes, a reboot
is required.
No 2.0 Ye s Yes
NETWORK.DHCP DHCP 1207 =?+- 0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
NETWORK.DHCP?
NETWORK.DHCP:ON
Toggles the equipment to use dynamic
host configuration protocol. For static IP
enabling, see IPV4.ENABLE.
No 1.x Yes Yes
NETWORK.DNS1 DNS Server 1 1212 =? 0=ACTIVE
1=STATIC
[None = ACTIVE (for reads
only)]
[None = STATIC (for writes
only)]
String NETWORK.DNS1(0)?
NETWORK.DNS1(0):"192.168.1.10"
Gets / sets the domain name server of the
equipment.
No 1.x Yes Yes
NETWORK.DNS2 DNS Server 2 1213 =? 0=ACTIVE
1=STATIC
[None = ACTIVE (for reads
only)]
[None = STATIC (for writes
only)]
String NETWORK.DNS2(0)?
NETWORK.DNS2(0):"192.168.1.20"
Gets / sets the backup domain name server
of the equipment.
No 1.x Yes Yes
NETWORK.MAC Component MAC
Address
1203 ? PS#
VC#
PSW#
String NETWORK.MAC?
NETWORK.MAC:"12:34:56:AB:CD:EF"
NETWORK.MAC(VC2)?
NETWORK.MAC(VC2):C4:F3:12:73:77:04
Returns the master component MAC
address. No modifier returns the master
component MAC address.
No 1.x
10.0
1
Yes Yes
NETWORK.PING Network Ping 1211 = String NETWORK.PING=10.15.0.60
NETWORK.PING:"0"
Pings other network IP addresses.
"0" = Time out (10 seconds)
"1" = Success
No 1.x Yes Yes
NTP.ENABLE Network Time
Protocol Enable
1209 =? 0=OFF
1=ON
NTP.ENABLE=ON
NTP.ENABLE:ON
Enables or disables NTP. Yes 5.1 Ye s Yes
NTP.SERVER Network Time
Protocol Server
1214 =? See Table: Time Zone
Setting-Operands
NTP.SERVER="0.pool.us.ntp.org"
NTP.SERVER:"0.pool.us.ntp.org"
Gets / sets the NTP server used by the NTP
client.
Yes 5. 1 Ye s Yes
OSD.ALLOW.
POPUP
OSD Popup 1300 =?+- 0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
OSD.ALLOW.POPUP?
OSD.ALLOW.POPUP:ON
Gets / sets the whether popup messages
will be displayed on the panels.
No 3.0 No No
OSD.MARGIN OSD Offset 1313 =?+- 0-400 OSD.MARGIN=10
OSD.MARGIN:10
Gets / sets the OSD position in pixels away
from edges set by OSD.POSITION. No effect
on OSD.POSITION=CENTER.
No 3.0 No No
Command Description
Numeric Command Code
Operators
Modifiers Operands Example Notes
Standalone Component Command
Firmware Version Active
Functional in Fast Start Standby
Functional in Low Power Standby
