RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 21
020-1332-00I
OSD.POSITION OSD Position 1301 =?+- 0=CENTER
1=UPPER.LEFT
2=UPPER.RIGHT
3=BOTTOM.LEFT
4=BOTTOM.RIGHT
OSD.POSITION=2
OSD.POSITION:UPPER.RIGHT
Positions the OSD on each panel to the
indicated position on the panel.
No 3.0 No No
OSD.TIMEOUT OSD Timeout 1304 =?+- 0=OFF
30=30.SECONDS
60=60.SECONDS
120=120.SECONDS
240=240.SECONDS
OSD.TIMEOUT?
OSD.TIMEOUT:60
Gets/ sets the output resolution to
automatically (default) detect the
connected panel resolution or provide a
method to manually set the mode to be
1920x1080 or 3840x2160 resolution.
Modifier is only used to query an individual
VC’s mode.
No 3.0 No No
OUTPUT.COLOR.
DEPTH
Bit Depth 603 =? 8, 10, 12 OUTPUT.COLOR.DEPTH?
OUTPUT.COLOR.DEPTH:10
Gets / sets the color bit depth processed by
the system.
No 9.0 Ye s No
OUTPUT.MODE VC Output
Resolution
604 =? VC# 0=AUTO
1=1080p
2=4K
OUTPUT.MODE=4k
OUTPUT.MODE:4K
OUTPUT.MODE(VC2)?
OUTPUT.MODE(VC2):4K
Gets / sets the output resolution to
automatically (default) detect the
connected panel resolution or provide a
method to manually set the mode to be
1920x1080 or 3840x2160 resolution.
Yes 7. 0 Ye s No
OUTPUT.
VREFRESH
Panel Refresh
Rate
605 =? 50
60
OUTPUT.VREFRESH=50
OUTPUT.VREFRESH:50
Gets / sets the system panel refresh rate.
Reboot required after setting.
No 7.0 Ye s No
PANEL.ACTIVE Panel Active Area 1522 =? Integer 0-65535 PANEL.ACTIVE(1)?
PANEL.ACTIVE(1):0 0 1280 720
Gets / sets the active area x, y, width, and
height in panel pixel coordinates
No 3.0 No No
PA NEL .
BRIGHTNESS.
OFFSET
Panel Brightness
Offset
1437 =?+- PN# -100 to 100 PANEL.BRIGHTNESS.OFFSET(PN1)=5
PANEL.BRIGHTNESS.OFFSET(PN1):5.000
000
Gets / sets the panel’s offset brightness for
use with color balancing
No 7.0 Ye s No
PANEL.COUNT Number of Panels 1527 ? Integer PANEL.COUNT?
PA NEL .CO UN T: 12
Returns the number of panels configured
in the system.
No 4.0 Yes No
PANEL.HEIGHT Panel Height in
Pixels
1544 ? PN# Integer PANEL.HEIGHT(10)?
PANEL.HEIGHT(10):720
Gets the pixel height of the specified panel. No 8.0
10.0
1
Yes Yes
PANEL.ID Set Panel ID 1524 = 1-65535 1-65535 PANEL.ID(5)=3
PANEL.ID(5):3
Sets an existing panel ID to a new panel ID.
If there are duplicate IDs, the first found will
be changed.
No 3.0 No No
Command Description
Numeric Command Code
Operators
Modifiers Operands Example Notes
Standalone Component Command
Firmware Version Active
Functional in Fast Start Standby
Functional in Low Power Standby
