PANEL.LIST Panel ID List 1526 ? Integer 1-PANEL.COUNT
…..and/or….
Integer 1-PANEL.COUNT
String PANEL.LIST?
PANEL.LIST:1 2 3 5 6 7 8 9 10
PANEL.LIST(3)?
PANEL.LIST:3
PANEL.LIST(4 8)?
PANEL.LIST:4 5 6 7 8
Returns a list of up to 64 panel IDs that are
currently recognized by the system. The
optional modifiers enable listing when
there are more than 64 panels. The first
modifier gives the 1-based index into the
list for the first returned value. If the second
modifier is omitted, only one value is
returned. When given, the second value
specifies the end index of the returned
values.
No 4.0 Ye s No
PANEL.POSITION Panel Array
Position
1528 ? PN# String PANEL.POSITION(PN2)?
PANEL.POSITION(PN2):3 2
Returns the column/row postion in an
array of the specified panel.
No 4.0 Yes No
PA NEL .R EC T Panel Display
Area
1529 ? Integer Integer PAN EL .REC T( 5) ?
PANEL.RECT(5):1920 1080 1920 1080
For specified panel in configured wall,
returns in order: x offset dimension from
zero x position in wall, y offset dimension
from zero y position in wall, x display pixels,
y display pixels.
No 4.0 Ye s No
PANEL.WIDTH Panel Width in
Pixels
1543 ? PN# Integer PANEL.WIDTH(10)?
PANEL.WIDTH(10):1080
Gets the pixel width of the specified panel. No 8.0
10.0
1
Yes Yes
PA NEL .X Y Cabinet Origin 1537 ? Integer PANEL.XY(3)?
PANEL.XY(3):0 2160
Returns the pixel position of the 0,0
coordinate of the specified panel in X and Y
dimensions.
No 6.0 Ye s No
PATTERN Test Pattern 1307 =? 0=NONE
1=BLACK
2=WHITE
3=RED
4=GREEN
5=BLUE
6=CYAN
7=MAGENTA
8=YELLOW
9=GRAY
10=CUSTOM_COLOR
11=RED_SCALE
12=GREEN_SCALE
13=BLUE_SCALE
14=GRAY_SCALE
15=LOGO
16=GRID
18=CONTRAST
20=COLOR_BARS
PAT T ERN ?
PATTERN:GREEN
Gets / sets the test pattern displayed for all
displays connected to the system.
No 2.0 No No
