Planar RPS - Page 23

RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 23
020-1332-00I
POWER.SAVING.
DELAY
No Source Power
Mode Time
1439 =? 0=CUSTOM
60=1.MINUTE
300=5.MINUTES
900=15.MINUTES
1800=30.MINUTES
3600=60.MINUTES
POWER.SAVING.DELAY=900
POWER.SAVING.DELAY:900
POWER.SAVING.DELAY?
POWER.SAVING.DELAY:15.MINUTES
Gets / sets the time the system will wait
before activating the POWER.SAVE.MODE.
See POWER.SAVING.DELAY.MINUTES for
custom times.
No 8.0 Ye s Yes
POWER.SAVING.
DELAY.MINUTES
No Source Power
Mode Custom
Time
1440 =? 1.000000 thru
120.000000
POWER.SAVING.DELAY.MINUTES=100
POWER.SAVING.DELAY.MINUTES:100.00
0000
Gets / sets the custom time for
POWER.SAVING.DELAY.
No 8.0 Yes Yes
POWER.SAVING.
MODE
No Source Power
Mode
1440 =? 0=DISABLED
1=FAST.START
2=LOW.POWER
POWER.SAVING.MODE?
POWER.SAVING.MODE:DISABLED
Gets / sets the system power mode for
when a source displayed on the video wall
is absent.
No 8.0 Ye s Yes
PS.COUNT Number of Power
Supplies
1428 ? Integer PS.COUNT?
PS.COUNT:4
Returns the number of power supplies
configured in the system.
No 4.0 Yes No
PS.LIST Power Supply ID
List
1427 ? Integer 1-PS.COUNT
…..and/or….
Integer 1-PS.COUNT
String PS.LIST?
PS.LIST:1 2 3 4
PS.LIST(3)?
PS.LIST:3
PS.LIST(1 3)?
PS.LIST:1 2 3
Returns a list of up to 64 power supply IDs
that are currently recognized by the
system. The optional modifiers enable
listing when there are more than 64 power
supplies. The first modifier gives the 1-
based index into the list for the first
returned value. If the second modifier is
omitted, only one value is returned. When
given, the second value specifies the end
index of the returned values.
No 4.0 Ye s No
PS.VERSION Power supply
module software
version
2318 ? 1-4 String PS.VERSION(2)?
PS.VERSION(2):"1.0.600"
Returns the firmware version of the
indicated power supply module within the
directly connected power supply.
Yes 1. x Yes No
RESET Factory Reset 2400 ! RESET
RESET:@ACK
Resets the system to factory defaults. Full
AC power cycle may be required or system
reboot.
No 1.x Yes No
RESET.CANCEL Cancel Factory
Reset
2406 ! RESET.CANCEL
RESET.CANCEL:@ACK
Cancels pending factory reset prior to
reboot or AC cycle.
No 2.0 Yes Yes
RESET.LAYOUT Reset Wall Layout 609 ! RESET.LAYOUT
RESET.LAYOUT@ACK
Resets wall layout back to default. No 7.0 Yes No
SERIAL.DEVICE Serial Baud Rate 1220 =? 9600
19200
38400
57600
115200
SERIAL.DEVICE?
SERIAL.DEVICE:19200
Gets / sets the baud rate for the connected
component. Default is 19200. Note: Data
bits, parity and stop bits are always 8, N, 1.
Yes 2. 0 Ye s Yes
Command Description
Numeric Command Code
Operators
Modifiers Operands Example Notes
Standalone Component Command
Firmware Version Active
Functional in Fast Start Standby
Functional in Low Power Standby
