RS232 Codes
Planar RPS and Video Controller RS232 User Guide Page | 24
020-1332-00I
SERIAL.NUMBER Component
Serial number
2303 ? PS#
VC#
PN#
String SERIAL.NUMBER(PN1)?
SERIAL.NUMBER(PN1):"ABCD1234"
No modifier returns the directly attached
component serial number. Using a modifier
returns the serial number of the specified
equipment.
Yes 1.x
4.0
1
Yes No
SOURCE.ABSENT.
COLOR
No Source
Display Color
606 =? 0=BLACK
1=GRAY
2=RED
3=GREEN
4=BLUE
5=CYAN
6=YELLOW
7=MAGENTA
8=CUSTOM
SOURCE.ABSENT.COLOR=2
SOURCE.ABSENT.COLOR:2
Gets / sets the configured color for a zone
when an expected source is absent.
No 7.0 Yes No
SOURCE.ABSENT.
RGB
Custom No
Source Display
Color
607 =? 0 to 1023 SOURCE.ABSENT.RGB=1000 1000 1000
SOURCE.ABSENT.RGB:1000 1000 1000
Gets / sets the custom color option in
SOURCE.ABSENT.COLOR. Three values
entered in order are Red, Green, Blue.
Setting automatically sets
SOURCE.ABSENT.COLOR to CUSTOM.
No 7.0 Ye s No
STANDBY.MODE Power Standby
Mode
1425 =? 0=FAST.START
1=LOW.POWER
STANDBY.MODE?
STANDBY.MODE:FAST.START
Gets / sets the power standby mode of the
system.
No 4.0 Yes Yes
SYSTEM.PANEL.
VERSION
Panel Firmware
Version
2322 ? String SYSTEM.PANEL.VERSION?
SYSTEM.PANEL.VERSION:"1.5.267"
Returns the panel firmware version. No 5.1 Ye s No
SYSTEM.POWER.
TIE
External Device
Power Behavior
2705 =? PSW#
ALL
0=NO
1=FAST.START
2=LOW.POWER
3=CUSTOM
SYSTEM.POWER.TIE(PSW5)?
SYSTEM.POWER.TIE(PSW5):FAST.START
SYSTEM.POWER.TIE(ALL)=2
SYSTEM.POWER.TIE(ALL):2
Gets / sets the specified external power
device behavior based on the system
power mode.
No 8.0 Yes Yes
TIMEZONE Time Zone
Setting
1208 =?+- See "Time Zone
Setting–Operands" on
page 26.
TIMEZONE=5
TIMEZONE:5
TIMEZONE=UTCM0800.PACIFIC.TIME.US.
CANADA
TIMEZONE:UTCM0800.PACIFIC.TIME.US.
CANADA
Gets / sets the timezone for the system. Yes 5.1 Ye s Yes
TIMEZONE.
STRING
Time Zone Status 1221 ? String TIMEZONE.STRING?
TIMEZONE.STRING:"(UTC-08:00) Pacific
Time (US & Canada)"
Returns the timezone string for the system. Yes 5.1 Yes Yes
VC.AUTO.
ADDRESS.ENABLE
Automatic VC IP
Address
2328 =? 0=DISABLE=OFF=NO=
FALSE
1=ENABLE=ON=YES=
TRUE
VC.AUTO.ADDRESS.ENABLE?
VC.AUTO.ADDRESS.ENABLE:TRUE
Gets / sets the system auto setting of
individual IP addresses on the static
network.
No 8.0 Ye s Yes
VC.COUNT Number of Video
Controllers
1604 ? Integer VC.COUNT?
VC.COUNT:4
Returns the number of video controllers
configured in the system.
No 4.0 Yes No
