PLANET ECLIPSE EMF100 - Technical; Parts List

FIG-1
34 35
EMF100 EMF100
TECHNICAL
PARTS LIST
TECHNICAL
PARTS LIST
8
7
9
10
14
16
4
17
1
5
6
2
15
11
13
12
3
FIG-1
1
Feedtube plug / Clamping feedtube assembly
2
Marker body shell
3
Back cap
4
Bolt assembly
5
Rubber detent
6
Safety switch
7
Three-way assembly
8
Rear frame screw
9
Front frame screw
10
Frame assembly
11
Trigger assembly
12
Grip retaining clip
13
Regulator assembly
14
Magazine well
15
ASA assembly
16
Magazine release catch assembly
17
Barrel o-ring #016 NBR70
