2.1.1 Switch Front Panel
Figure 2-1 shows the front panel of Industrial Gigabit Ethernet Switch.
6
LNK /
ACT
SFP
1000X
1000X
P1 P2 FAULT
5
4
3
2
1
IGS-620TF
1000 LNK/ACT
100 LNK/ACT
LNK /
ACT
SFP
Figure 2-1: IGS-620TF Front Panel
