2.1.2 LED Indicators
System
LED Color Function
P1 Green Lit: indicates power 1 has power.
P2 Green Lit: indicates power 2 has power.
FAULT Green
Lit: indicates either power 1 or power 2 has no
power.
Per 10/100/1000T Port
LED Color Function
100
LNK/ACT
Orange
Lit: indicates the link through that port is
successfully established at 100Mbps or 10Mbps.
Blinking: indicates that the Switch is actively
sending or receiving data over that port.
Off: indicates the link through that port is
successfully established at 1000Mbps.
1000
LNK/ACT
Green
Lit: indicates the link through that port is
successfully established at 1000Mbps or 10Mbps.
Blinking: indicates that the Switch is actively
sending or receiving data over that port.
Off: iindicates the link through that port is
successfully established at 100Mbps.
Per 100 / 1000X SFP Slots
LED Color Function
LNK/ACT Green
Lit: indicates the link through that port
is successfully established at 100Mbps or
1000Mbps.
Blinking: indicates that the Switch is actively
sending or receiving data over that port or the
port operate.
