The Industrial Gigabit Ethernet Switch has two SFP interfaces that
support 100/1000 dual speed mode (Optional Multi-mode / Single-
mode 100BASE-FX / 1000BASE-SX/LX SFP module) through DIP switch
setting.
Cabling
Each 10/100/1000BASE-T port uses RJ45 sockets -- similar to phone
jacks -- for connection of unshielded twisted-pair cable (UTP). The
IEEE 802.3 / 802.3u / 802.3ab Fast / Gigabit Ethernet standard
requires Category 5 UTP for 100Mbps 100BASE-TX. 10BASE-T networks
can use Cat3, 4, 5 or 1000BASE-T uses Cat5/5e/6 UTP (see table
below). Maximum distance is 100 meters (328 feet). The 100BASE-FX
/ 1000BASE-SX/LX SFP slot is used as LC connector with optional
SFP module. Please see table below and know more about the cable
specications.
Port Type Cable Type Connector
10BASE-T Cat3, 4, 5, 2-pair RJ45
100BASE-TX Cat5 UTP, 2-pair RJ45
1000BASE-T Cat5/5e/6 UTP, 4-pair RJ45
100BASE-FX
50 / 125µm or 62.5 / 125µm multi-
mode 9 / 125µm single-mode
LC (Multi /
Single mode)
1000BASE-SX/
LX
50 / 125µm or 62.5 / 125µm multi-
mode 9 / 125µm single-mode
LC (Multi /
Single mode)
Any Ethernet devices like hubs/PCs can be connected to the Industrial
Gigabit Ethernet Switch by using straight-through wires. The four
10/100/1000Mbps ports are auto-MDI/MDI-X and can be used on
straight-through or crossover cable.
2.1.6.1 Installing the SFP Transceiver
The sections describe how to insert an SFP transceiver into an SFP slot.
The SFP transceivers are hot-pluggable and hot-swappable. You can
plug in and out the transceiver to/from any SFP port without having
to power down the Industrial Gigabit Ethernet Switch as Figure 2-3
shows.
