2. INSTALLATION
This section describes the functionalities of the Industrial Gigabit
Ethernet Switch’s components and guides how to install it on the
desktop. Basic knowledge of networking is assumed. Please read this
chapter completely before continuing.
In the following section, the term “Industrial Gigabit Ethernet Switch”
means the IGT-501 / IGT-801 / IGT-501T / IGT-801T.
2.1 Product Description
The PLANET IGT-501 / IGT-801 / IGT-501T / IGT-801T is 5/8-Port
10/100/1000Mbps Industrial Gigabit Ethernet Switch with non-blocking
wire-speed performance and new slim type with IP 30 metal shape for
easily deployment in Heavy Industrial demanding environments.
With a 10/16Gbps internal switching fabric, the Industrial Gigabit
Ethernet Switch can handle extremely large amounts of data in a
secure topology linking to a backbone or high capacity servers.
The Industrial Gigabit Ethernet Switch has 8K MAC Address table and
offers wire-speed packets transfer performance without risk of packet
loss. The Gigabit ports with 9K jumbo packet support can handle
large amounts of data transmission in a secure topology linking to a
backbone or high-power servers. The high data throughput of the
device makes it ideal for most Gigabit environments.
All RJ-45 copper interfaces support 10/100/1000Mbps Auto-Negotiation
for optimal speed detection through RJ-45 Category 6, 5 or 5e cables.
Support standard for Auto-MDI/MDI-X that can detect the type of
connection to any Ethernet device without requiring special straight or
crossover cables.
The Flow Control function allows Industrial Gigabit Ethernet Switch
supported routers and Servers to directly connect to this device for
fast, reliable data transfer.

Planet IGS-801T Specifications

General

Switch type	Unmanaged
Switch layer	L2
Quality of Service (QoS) support	Yes
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Stackable	-
Certification	FCC, CE
Product color	Blue
Rack mounting	No
Housing material	Metal
International Protection (IP) code	IP30
Power consumption (typical)	6.72 W
Heat dissipation	23 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e, Cat6
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Throughput	11.9 Mpps
Jumbo frames	9000
MAC address table	4000 entries
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87 mm
Width	32 mm
Height	135 mm
Weight	476 g
