1. INTRODUCTION
1.1 Package Contents
Check the contents of your package for following parts:
Industrial Gigabit Ethernet Switch x 1
User's manual x 1
DIN rail kit x 1
Wall mount kit x 1
If any of these are missing or damaged, please contact your dealer
immediately, if possible, retain the carton including the original packing
material, and use them against to repack the product in case there is a
need to return it to us for repair.
1.2 How to Use This Manual
This Industrial Gigabit Ethernet Switch User Manual is structured as
follows:
Chapter 2 Installation
The chapter explains the feature, functionality and the physical
installation of the Industrial Gigabit Ethernet Switch.
Chapter 3 Application
The chapter explains the Industrial Gigabit Ethernet Switch application.
Chapter 4 Switch operation
The chapter explains the Industrial Gigabit Ethernet Switch transmit
operation.
Chapter 5 Troubleshooting
The chapter explains the troubleshooting of the Industrial Gigabit
Ethernet Switch.
Appendix A
This chapter contains cable information of the Industrial Gigabit
Ethernet Switch.
l
l
l
l

Planet IGS-801T Specifications

General

Switch type	Unmanaged
Switch layer	L2
Quality of Service (QoS) support	Yes
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Stackable	-
Certification	FCC, CE
Product color	Blue
Rack mounting	No
Housing material	Metal
International Protection (IP) code	IP30
Power consumption (typical)	6.72 W
Heat dissipation	23 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e, Cat6
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Throughput	11.9 Mpps
Jumbo frames	9000
MAC address table	4000 entries
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87 mm
Width	32 mm
Height	135 mm
Weight	476 g
