Planet IGS-801T User Manual

7
1.3 Product Features
Physical Port
5-Port 10/100/1000Base-T RJ-45 with auto MDI/MDI-X function (IGS-
501 / IGS-501T)
8-Port 10/100/1000Base-T RJ-45 with auto MDI/MDI-X function (IGS-
801 / IGS-801T)
Layer 2 Features
Complies with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE
802.3ab 1000Base-T Ethernet standard
Supports Auto-negotiation and 10/100Mbps half / full duplex and
1000Mbps full duplex mode
High performance Store and Forward architecture, broadcast storm
control, runt/CRC ltering eliminates erroneous packets to optimize
the network bandwidth
Prevents packet loss with back pressure (Half-Duplex) and IEEE
802.3x PAUSE frame ow control (Full-Duplex)
Backplane (Switching Fabric): IGS-501 / IGS-501T: 10Gbps, IGS-801
/ IGS-801T: 16Gbps
Integrated address look-up engine, support 8K absolute MAC
addresses
136 kilobytes on-chip frame buffer on IGS-501 / IGS-501T
176 kilobytes on-chip frame buffer on IGS-801 / IGS-801T
9K Jumbo packet size support
Automatic address learning and address aging
CSMA/CD Protocol
Industrial Case / Installation
IP-30 Metal case / Protection
DIN Rail and Wall Mount Design
12 to 48V DC, redundant power with polarity reverse protect function
and connective removable terminal block for master and slave power
-10 to 60 Degree C operation temperature on IGT-501 / IGT-801
-40 to 75 Degree C operation temperature on IGT-501T / IGT-801T
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l

Planet IGS-801T Specifications

General

Switch type	Unmanaged
Switch layer	L2
Quality of Service (QoS) support	Yes
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Stackable	-
Certification	FCC, CE
Product color	Blue
Rack mounting	No
Housing material	Metal
International Protection (IP) code	IP30
Power consumption (typical)	6.72 W
Heat dissipation	23 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e, Cat6
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Throughput	11.9 Mpps
Jumbo frames	9000
MAC address table	4000 entries
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87 mm
Width	32 mm
Height	135 mm
Weight	476 g
