Planet IGS-801T User Manual

20
4. SWITCH OPERATION
4.1 Address Table
The Industrial Gigabit Ethernet Switch is implemented with an address
table. This address table composed of many entries. Each entry is used
to store the address information of some node in network, including
MAC address, port no, etc. This information comes from the learning
process of Industrial Gigabit Ethernet Switch.
4.2 Learning
When one packet comes in from any port. The Industrial Gigabit
Ethernet Switch will record the source address, port no. And the other
related information in address table. This information will be used to
decide either forwarding or ltering for future packets.
4.3 Forwarding & Filtering
When one packet comes from some port of the Industrial Gigabit
Ethernet Switch, it will also check the destination address besides the
source address learning. The Industrial Gigabit Ethernet Switch will
lookup the address-table for the destination address. If not found, this
packet will be forwarded to all the other ports except the port which
this packet comes in. And these ports will transmit this packet to the
network it connected. If found, and the destination address is located at
different port from this packet comes in, the Industrial Gigabit Ethernet
Switch will forward this packet to the port where this destination
address is located according to the information from address table.
But, if the destination address is located at the same port with this
packet comes in, then this packet will be ltered. Thereby increasing
the network throughput and availability.

Planet IGS-801T Specifications

General

Switch type	Unmanaged
Switch layer	L2
Quality of Service (QoS) support	Yes
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Stackable	-
Certification	FCC, CE
Product color	Blue
Rack mounting	No
Housing material	Metal
International Protection (IP) code	IP30
Power consumption (typical)	6.72 W
Heat dissipation	23 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e, Cat6
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Throughput	11.9 Mpps
Jumbo frames	9000
MAC address table	4000 entries
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87 mm
Width	32 mm
Height	135 mm
Weight	476 g
