Planet IGS-801T User Manual

22
5. TROUBLESHOOTING
This chapter contains information to help you solve issues. If the
Industrial Gigabit Ethernet Switch is not functioning properly, make
sure the Industrial Gigabit Ethernet Switch was set up according to
instructions in this manual.
The per port LED is not lit
Solution:
Check the cable connection of the Industrial Gigabit Ethernet Switch.
Performance is bad
Solution:
Check the speed duplex mode of the partner device. The Industrial
Gigabit Ethernet Switch is run at Auto-negotiation mode and if the
partner is set to half duplex, then the performance will be poor.
Per port LED is lit, but the trafc is irregular
Solution:
Check that the attached device is not set to dedicate full duplex. Some
devices use a physical or software switch to change duplex modes.
Auto-negotiation may not recognize this type of full-duplex setting.
Why the Industrial Gigabit Ethernet Switch doesn’t connect to
the network
Solution:
Check per port LED on the Industrial Gigabit Ethernet Switch. Try
another port on the Industrial Gigabit Ethernet Switch Make sure the
cable is installed properly Make sure the cable is the right type Turn off
the power. After a while, turn on power again.
Why the Industrial Gigabit Ethernet Switch doesn’t connect to
the network
Solution:
Check per port LED on the Industrial Gigabit Ethernet Switch. Try
another port on the Industrial Gigabit Ethernet Switch Make sure the
cable is installed properly Make sure the cable is the right type Turn off
the power. After a while, turn on power again.

Planet IGS-801T Specifications

General

Switch type	Unmanaged
Switch layer	L2
Quality of Service (QoS) support	Yes
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Stackable	-
Certification	FCC, CE
Product color	Blue
Rack mounting	No
Housing material	Metal
International Protection (IP) code	IP30
Power consumption (typical)	6.72 W
Heat dissipation	23 BTU/h
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e, Cat6
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Throughput	11.9 Mpps
Jumbo frames	9000
MAC address table	4000 entries
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	87 mm
Width	32 mm
Height	135 mm
Weight	476 g
