19
Refer to the following procedures to set up the VC-234G/
VC-231G LAN to LAN connection.
1. [LAN1] Set the VC-234G/VC-231G at LAN 1 to be CO mode
from the DIP switch.
2. [LAN2] Set the VC-234G/VC-231G at LAN 2 to be CPE mode
from the DIP switch.
3. Power on the VC-234G/VC-231G CO and CPE at both sides by
connecting its power source.
4. Power LED will illuminate.
5. Connect VDSL line from another VDSL device to RJ11 VDSL
port of the VC-234G/VC-231G.
6. VDSL LNK LED will blink to illuminate at both VDSL2
bridges.
7. Connect telephone to the RJ11 Phone port of the VC-234G/
VC-231G.
8. Connect VC-234G/VC-231G Ethernet LAN port to other
network device via regular Cat.5 UTP cable.
4.2 Point-to-Multipoint Application -- Connect to IP
DSLAM
To build a local Internet in apartments, hotels and campuses
and hospitality environments, it requires:
The multi-port VDSL2 IP DSLAM or VDSL2 switch (for example,
PLAMET VDL-2420M and VC-820M) operates as a CO Master
and needs to be placed in the wiring center (MDF room) and
connect to the telephone line system.
On the other hand, it needs to install one or many CPE Slaves
(VC-231G or VC-234G VDSL Bridge) on the individual client side
and connect to the multi-port Master through the telephone
lines.
