15
3.3 Power Information
The power jack of VC-231G and VC-234G measures 2.5mm in
the central post and requires +5VDC power input. It conforms
to the bundled AC-DC adapter and Planet’s Media Chassis.
Should you have the issue of power connection, please contact
your local sales representative.
Please keep the AC-DC adapter as a spare part when your
VC-231G is installed to a Media Chassis.
2.5mm
DC Receptacle 2.5mm
+5V for each slot
DC receptacle is 2.5mm wide that conforms to and
matches the VDSL2 Converter 2.5mm DC jack’s central
post. Do not install any improper unit, model of the VDSL2
Bridge.
