Planet VC-234G User Manual

22
5.ProductSpecications
Product VC-231G VC-234G
Hardware Specications
LAN Ports
1 10/100/1000BASE-T
RJ45 auto-MDI/MDI-X
ports
4 10/100/1000BASE-T
RJ45 auto-MDI/MDI-X
ports
VDSL Port
1 VDSL2 RJ11 female phone jack
Twisted-pair telephone wires (AWG24 or better)
up to 1.4km
Phone Port
Additional splitter for
POTS connection
1 RJ11, built-in splitters
for POTS connection
Dimensions
(W x D x H)
97 x 70 x 26 mm
154.6 x 86.0 x 26.3
mm
Weight 184g 350g
Power
Requirement
DC 5V, 2A external power
LED Indicators
 Power: Green
 1000BASE-T LNK/ACT: Green
 100BASE-T LNK/ACK: Green
 VDSL: Green
 CO: Green
 CPE: Green
Housing Metal
DIP Switch &
Functionality
4-position DIP switch
 CO/CPE mode select
 Selectable G.INP and interleaved mode
 Selectable target Band plan
 Selectable target SNR mode
