21
4. Power LED will illuminate.
5. Connect VDSL line from IP DSLAM/VDSL2 switch to RJ11
VDSL port of the VC-234G/VC-231G.
6. VDSL LNK LED will blink to illuminate.
7. Connect telephone to the RJ11 Phone port of the VC-234G/
VC-231G.
8. Connect VC-234G/VC-231G Ethernet LAN port to other
network device via regular Cat.5 UTP cable.
When deciding where to put the converter and / or prolong the
operational life of the bridge, please also refer to the following
points:
¾ It is accessible and cables can be connected easily.
¾ Cabling is away from sources of electrical noise such as
radios, transmitters, motors, power lines and uorescent
lighting xtures.
¾ Do not place objects on top of any unit or stack
¾ Water or moisture cannot enter the VDSL2 Bridge.
¾ Air owing around the unit and through the vents in the side
of the case is not restricted (We recommend that you provide
a minimum of 25mm clearance).
