4.2 Control panel
One end of the control panel cable is connected to the
terminal at the underside of the generator box, and the
other end to the control panel.
CAUTION Do not connect any other equipment to the
control panel’s terminal.
intra_stiffness.eps
Horizontal tube head stiffness
adjustment screw
