Planmeca Intra X-ray Unit 7
PREPARATIONS FOR THE EXPOSURE
User’s Manual
5 PREPARATIONS FOR THE EXPOSURE
5.1 Switching the unit on
The on/off switch is located under the generator box.
When the unit is switched on it will carry out an automatic
self-test during which the Display CPU software version is
shown on the kV display, and the Tube head CPU
software version on the time display.
After the self-test is completed the default exposure
values will appear on the displays.
The default exposure values can be reprogrammed by the
user, see section 14.1 “Programming the default
exposure and density values” on page 39.
NOTE There are two sets of default exposure values: one for
the adult mode and one for the child mode. The unit is
always in the adult mode when it is switched on.
I_6.eps
R
E
A
D
Y
P
R
E
T
m
A
k
V
s
B
W
S
E
L
E
C
T
M
O
D
E
Complies with
DHHS radiation
performance
standards
21 CFR
Subchapter J.
220V - 240 V AT
AT
8
100V - 115 V 15
70kV maximum 1800 mAs/h
Total filtration: 2,0 mm EquAl
WARNING:
For continued protection
against risk of fire replace
only with same type and
rating of fuse.
Manufactured by:
Planmeca OY
00880 HELSINKI
FINLAND
LBL-Z-006D
1000VA 50/60Hz
0537
On/off switch

Planmeca intra Specifications

General

Manufacturer	Planmeca
Model	Planmeca Intra
Frequency	50/60 Hz
Tube Voltage	60-70 kV
Tube Current	7 mA
Type	Dental X-ray Unit
Voltage	100-240 V
Weight	Varies depending on configuration; refer to specific model documentation
