Planmeca Intra X-ray Unit 41
PROGRAMMING THE EXPOSURE VALUES
User’s Manual
NOTE Both the child and adult mode have the same density
values.
NOTE If you interrupt programming for over 45 seconds, the
unit automatically exits the programming mode, and
the current values will be stored in the memory.
14.2 Programming the preprogrammed settings
NOTE Two sets of exposure values (time/kV/mA) can be pro-
grammed for each exposure region: one for adult
mode and one for child mode. The indicator light of
the selected projection will come on.
NOTE The exposure parameters - time, kV and mA - are pro-
grammed corresponding to the density value 0. The
time value will be automatically changed according to
the selected density value in the film-based imaging
mode, in the digital imaging mode and in the phos-
phoric mode when you exit the programming mode.
Select the exposure region with the preprogrammed
setting keys. Press the desired key once to select the
projection of the maxilla, and press the key twice to select
the projection of the mandible. The indicator light of the
selected projection will come on.
The current time, kV and mA values appear on the
respective displays.
Press and hold down the SELECT key (about 4 seconds)
until you have heard a signal tone to enter the
programming mode. The time display and the ready light
will start to flash.
The imaging mode can be changed by pressing the
MODE key briefly.
Incisors
Premolars
and
canines
Molars
Occlusal
exposure
Bite-wing
Adult/
child
mode
selection
Endo-
dontic

Planmeca intra Specifications

General

Manufacturer	Planmeca
Model	Planmeca Intra
Frequency	50/60 Hz
Tube Voltage	60-70 kV
Tube Current	7 mA
Type	Dental X-ray Unit
Voltage	100-240 V
Weight	Varies depending on configuration; refer to specific model documentation
