Planmeca Intra X-ray Unit 9
PREPARATIONS FOR THE EXPOSURE
User’s Manual
When attaching the film to the holder make sure that the
film is in the same direction as the rectangular collimator.
NOTE The exposure values must be selected according to
the cone used in the exposure, refer to the section 13
“EXPOSURE VALUES” on page 36.
RINN film holder
Attach the RINN compatible rectangular collimator to the
long cone. The film holder can be attached to the
collimator.
Film and collimator sides
in the same direction
RINN compatible
rectangular collimator
RINN film holder

Planmeca intra Specifications

General

Manufacturer	Planmeca
Model	Planmeca Intra
Frequency	50/60 Hz
Tube Voltage	60-70 kV
Tube Current	7 mA
Type	Dental X-ray Unit
Voltage	100-240 V
Weight	Varies depending on configuration; refer to specific model documentation
