Plexxi Switch 2e - Verify Equipment

!
+#! HE)QQ7!?O73/A!')!B<5RO<5)!<2R!;263<EE<37. 2 ! S07R)! !
4)57Z>!J]07P1)23!!
Review the components to ensure you received what your ordered.
Equipment
Description
Four hot swappable fans
Installed in chassis. A blue bar indicates airflow from
the power supply panel to the I/O end. A red bar
indicates airflow from I/O end to power supply panel.
Two power supplies
Installed in chassis.
Two power cables
2.5 meters in length, which complies with appropriate
country standards, You need to connect those cables
to separate circuits for redundancy protection.
Cables
Verify you have to cables ordered for your installation.
PSI:
• Two 24 fiber MTP to 3x12-fiber MTP Breakout
cables for PSI interconnect (5M or 20M).
• Three 10 inch 24 fiber LightRail cables for single
PSI loopback if not connected to another PSI
device. You need additional cables for less than
six switches on the PSI.
• Two 24 fiber LightRail cables to be used to
connect PSI devices together or to connect Switch
2p/2sp switches to a PSI device. Available in 1, 3,
5, 10, 20 and 100M lengths. You need six cables
to connect PSIs if interconnecting PSIs.
Direct Connect:
• DAC Passive cable, QSFP-to-QSFP 26AWG
twinaxial cable, IEEE 802.3ba. Available in 1, 3, 5
and 7 meters.
• AOC cable supplied by Plexxi
Rack mount kit
Rack mount for the switch.
