Point Mobile PM67 - Install & Remove Battery; Install the Battery

PM67 Android 11 User Manual
Getting Started
12
© 2021 Point Mobile Co., Ltd. All rights reserved
Install & Remove Battery
Install the battery
1. Open the battery cover while pressing the battery cover release button.
Using the small hole on both sides of the cover, pull it up.
2. Align the connector (gold contact) of the battery with the battery connector of device.
3. Insert top of the battery directly into the top of the slot.
Caution: Don’t slide the battery over the battery connector of the device while inserting the
battery. It may damage the connector pin.
Figure 7 Open battery cover
Figure 8 Insert battery_1
