Point Mobile PM67 - Mounting Hand Strap for Gun Handle

PM67 Android 11 User Manual
Accessories
80
© 2021 Point Mobile Co., Ltd. All rights reserved
Mount hand strap
Mount the hand strap enclosed in the gun handle package, and bring the device more comfortable.
1. Slide the rope into the handle side hole, first.
2. Pass the other end through the loop of the rope, and pull it tight.
3. Thread the strap through the fixture side hole.
4. Slide the strap through the buckle and latch the buckle at the appropriate length.
Figure 105 Slide into the handle side hole
Figure 106 Pass strap through the fixture side hole
Figure 107 Latch buckle to secure the strap
