~-M:NCS~
SkyHuntcrt40~
MANL:INS:SH:X:XX
2.7 ANTENNA CABLE - CABL:BNC:SH:A:X2
Augusta ,2013
Rev25
An RG 400 cable with BNC ends attaches the Antenna to the El T. The cable will have a length of
2 meters (approx. 6 feet).
2.8 GPS QUICK DISCONNECT CABLE - CABL:GPS:SH:A:QD
This RG 400 cable with SMA ends will allow the ElT to be attached to the GPS antenna.
2.9 SKYKEY PROGRAMMER KEYY:XXP:SH:B:TS
SkyKey Programmer for Fleet Operators, installed in each aircraft and programmed with specific
El T and Aircraft information so that an alternate El T can be placed on board reducing "down
time" for aircraft. The SkyKey is blue to indicate the additional capabilities it has when used to
connect the Remote Switch to the Skyhunter
406™.
2.10 SKYKEY MAINTENANCE KEYY:XXM:SH:R:XX
SkyKey Maintenance Programmer is used to return the SkyHunter 406 ™ ElT back to default
settings. After using a SkyKey Maintenance Programmer, the ElT will have to be re-·
programmed. The Maintenance Programmer is red to denote that it will remove the aircraft ID
if attached to the SkyHunter 406™.
2-2
