5.2
BODY / STEERING / SUSPENSION
TORQUE SPECIFICATIONS
NOTE: Refer to exploded views throughout this
chapter for more torque specifications, component
identification, and location of components.
SPECIAL TOOLS
ITEM TORQUE VALUE
ft.lbs. (Nm)
Front A-Arm Attaching Bolt 30 ft. lbs. (41 Nm)
Front A-Arm Ball Joint Stud Nut 30 ft. lbs. (41 Nm)
Rear Shock Bolt (upper) 30 ft. lbs. (41 Nm)
Rear Shock Bolt (lower) 30 ft. lbs. (41 Nm)
Rear Wheel Hub Nut 110 ft. lbs. (150 Nm)
Mid Half Shaft Castle Nut (6x6) 110 ft. lbs. (150 Nm)
Wheel Nuts (Cast Rims)
Wheel Nuts (Steel Rims)
90 ft. lbs. (122 Nm)
35 ft. lbs. (47 Nm)
Upper / Lower Control Arm
Mounting Bolt
30 ft. lbs. (41 Nm)
Mid Axle Upper / Lower Control
Arm Mounting Bolt (6x6)
35 ft. lbs. (47 Nm)
Lower Middle Wheel Bearing
Carrier Bolt (6x6)
35 ft. lbs. (47 Nm)
Lower Rear Wheel Bearing
Carrier Bolt
30 ft. lbs. (41 Nm)
Upper Middle Wheel Bearing
Carrier Bolt (6x6)
35 ft. lbs. (47 Nm)
Upper Rear Wheel Bearing
Carrier Bolt
30 ft. lbs. (41 Nm)
Strut Rod Retaining Nut (Top) 15 ft. lbs. (21 Nm)
Strut Casting Pinch Bolt 15 ft. lbs. (21 Nm)
Tie Rod End Jam Nut 12-14 ft. lbs. (17-19 Nm
Tie Rod End Castle Nut 40 ft. lbs. (54 Nm)
Seat Belt to Seat Base 40 ft. lbs. (54 Nm)
Steering Wheel to Shaft 25-31 ft. lbs. (34-42 Nm)
Upper Steering Shaft to
U-Joint Shaft
15-19 ft. lbs. (20-26 Nm)
Lower Steering Shaft to Box 30 ft. lbs. (41 Nm)
Steering Box 14-18 ft. lbs. (19-24 Nm)
TOOL DESCRIPTION PART NUMBER
Strut and Ball Joint Tool Set 2870871
Shock Spanner Wrench 2870872
Shock Spring Compressor Tool 2870623
Strut Spring Compressor Tool (LH) 2871573
Strut Spring Compressor Tool (RH) 2871574
