3.23
ENGINE
3
ENGINE DISASSEMBLY AND INSPECTION
Cylinder Head Assembly Exploded View
Push Rods
Hydraulic Lifters
Valves
Cylinder Head
Valve Seals
Springs
Spring Retainers
Rocker Arms
Retainer Locks (keepers)
Valve Spring Seats
