6.8
Drive and Brake Systems
9923396 - 2007-2012 EDGE/Widetrak LX Service Manual
©2011 Polaris Sales Inc.
20. Replace the top sprocket retaining nut.
21. Install cotter pin and bent the ends around the
jackshaft end.
22. Install the lower sprocket retaining bolt.
23. Release the parking brake.
24. Adjust the chain tensioner by hand and back off 1/4
turn.
25. Lock the adjuster lock nut.
26. Install the chaincase cover and fasteners.
27. Remove the fill cover and fill chaincase to the
appropriate level.
28. Check for leaks.
29. Adjust track tension to the specified tension.
Top Sprocket Nut: 62 ft.lb. (84 N-m)
Bottom Sprocket Bolt: 19 ft.lb. (26 N-m)
Chaincase Cover Bolts: 10 ft.lb. (13.5 N-m)
