8.37
Steering and Suspension Systems
8
9923396 - 2007-2012 EDGE/Widetrak LX Service Manual
©2011 Polaris Sales Inc.
TROUBLESHOOTING
Suspension Set-Up
PROBLEM SOLUTION
Rear suspension bottoms too easily.
Increase rear shock compression valving by turning screw
clockwise.
Increase torsion spring preload.
Install stiffer torsion springs.
Rides too stiff in rear.
Check for binding suspension shafts and grease all pivot points.
Decrease torsion spring preload adjustments.
Decrease rear shock compression valving by turning screw
counterclockwise.
Setting up for deep snow operation.
Change worn rail slides.
Increase front limiter strap length
Based on rider preference, RRSS may be removed to increase
weight transfer
