Polaris 340 LX 2007 User Manual

1.15
Model Specifications
1
9923396 - 2007-2012 EDGE/Widetrak LX Service Manual
©2011 Polaris Sales Inc.
General
Width (in/cm) 48 / 121.9
Length (in/cm) 113 / 287
Height (in/cm) 46 / 117
Estimated Dry Weight
(lb/kg)
481 / 218.4
Fuel (Gallons / Liters) 11.8 / 44.7
Oil (Quarts / Liters) 3.25 / 3.1
Brake Fluid DOT 4
Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)
3211080
1.438 / 3.65
28_
46.625 / 118.4
11.5 / 29.2
Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System
7.92
22
40
74
Polaris Synthetic
9 / 266.2
Perc
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 Vdc (Total)
13.5 - 14.5 Vdc
280
Ignition Timing
(Disconnect TPS)
25_ @ 2,500 RPM
Spark Plug Gap in.(mm) .027 (.70)
Spark Plug
Champion
RN57YCC
CDI Marking 4010829
Flywheel Marking 4010677
Track
Width - Inches (cm) 15 (38)
Length - Inches (cm) 121 (307)
Lug Height - Inches (cm)
.91 (2.3)
Euro = 1.25 (3.175)
Track tension sag in/cm
with 10 lbs/4.54kg placed
16 in/40cm ahead of rear
idler shaft
3/8” - 1/2” (1 - 1.3cm)
Front Suspension
Suspension Type EDGE 42.5
Shocks Arvin Nitrex Gas Bag
IFS Spring Rate
lbs/in (N/mm)
68 - 160 (1.22 - 2.9)
Spring Installed
Length
Inches (cm)
10.5 / 26.7
Front Vertical Travel
Inches (cm)
10 (25.4)
Suspension Width
Inches (cm)
40.44 +/- .25 (102.71 +/- .63)
Camber Inches (cm) .59 +/- .31 (1.5 +/- .8)
Toe Out Inches (cm)
(Measured over 20
inches)
.12 - .25 (.30 - .63)
Rear Suspension
Suspension Type EDGE 121
Front Track Shock (FTS) Arvin Nitrex Gas Bag
FTS Spring Rate
lbs/in (N/mm)
160 (2.86)
Rear Track Shock (RTS)
Ryde FX MPV
Compression Adjustable
Torsion Springs
.359 / 77_ (Soft)
- PN 7041629 - 067
- PN 7041630 - 067
.375 / 77_ (Stock)
- PN 7041942 - 067
- PN 7041943 - 067
Rear Travel Inches (cm) 13.9 (35.3)

Polaris 340 LX 2007 Specifications

General

Brand	Polaris
Model	340 LX 2007
Category	Offroad Vehicle
Language	English
