Model Specifications
1
9923396 - 2007-2012 EDGE/Widetrak LX Service Manual
©2011 Polaris Sales Inc.
General
Width (in/cm) 48 / 121.9
Length (in/cm) 128 / 325.1
Height (in/cm) 49.5 / 125.7
Estimated Dry Weight
(lb/kg)
570 / 258.8
Fuel (Gallons / Liters) 12.25 / 146.4
Oil (Quarts / Liters) 3.4 / 3.2
Brake Fluid DOT 4
Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)
3211078
1.438 / 3.65
28_
46.625 / 118.4
11.5 / 29.2
Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System
7.96
21
41
74
Polaris Synthetic
9 / 266.2
Perc
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 Vdc (Total)
13.5 - 14.5 Vdc
280
Ignition Timing
27_ @ 3500 RPM
14_ @ 6500 RPM
Spark Plug Gap in.(mm) .028 (.70)
Spark Plug NGK BR9ES
CDI Marking EC55PM100 / 110
Flywheel Marking FP6318
Track
Width - Inches (cm) 15 (38)
Length - Inches (cm) 136 (345.4)
Lug Height - Inches (cm) 1.0 / (2.5)
Track tension sag in/cm
with 10 lbs/4.54kg placed
16 in/40cm ahead of rear
idler shaft
7/8” - 1 1/8” (2.2 - 2.9cm)
Front Suspension
Suspension Type EDGE 42.5
Shocks
Arvin Nitrex
Compression Adjustable
IFS Spring Rate
lbs/in (N/mm)
100 (1.79)
Spring Pre-load
Inches (cm)
.625 (15.9)
Front Vertical Travel
Inches (cm)
10 (25.4)
Suspension Setup
Width
Inches (cm)
40.44 +/- .25 (102.71 +/- .63)
Camber Inches (cm) .59 +/- .31 (1.5 +/- .8)
Toe Out Inches (cm)
(Measured over 20
inches)
.12 - .25 (.30 - .63)
Rear Suspension
Suspension Type EDGE 136
Front Track Shock (FTS) Arvin Nitrex Gas Bag
FTS Spring Rate
lbs/in (N/mm)
200 - 240 (3.6 - 4.3)
Rear Track Shock (RTS)
Ryde FX MPV
Compression Adjustable
Torsion Springs
.405 / 77_ (Stock)
- PN 7041940 - 067
- PN 7041941 - 067
.375 / 77_ (Soft)
- PN 7041942 - 067
- PN 7041943 - 067
Rear Travel Inches (cm) 13.9 (35.3)
