Polaris 340 LX 2007 User Manual

1.35
Model Specifications
1
9923396 - 2007-2012 EDGE/Widetrak LX Service Manual
©2011 Polaris Sales Inc.
General
Width (in/cm) 43.5 / 110.5
Length (in/cm) 128 / 325.1
Height (in/cm) 51 / 129.5
Estimated Dry Weight
(lb/kg)
613 / 278.1
Fuel (Gallons / Liters) 11 / 41.6
Oil (Quarts / Liters) 2 / 1.9
Cooling System Capacity
(Quarts / Liters)
3.4 / 3.2
Brake Fluid DOT 4
Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)
3211070
1.375 / 3.49
28_
47.25 / 120
12 / 30.5
Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Drive System
N/A
19
41
66
Polaris Synthetic
20 / 591.5
HI / LOW / REV
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 Vdc (Total)
13.5 - 14.5 Vdc
200
Ignition Timing 27_ @ 3000 RPM
Spark Plug Gap in.(mm) .028 (.70)
Spark Plug Champion RN3C
CDI Marking IU2212
Flywheel Marking FP5536
Track
Width - Inches (cm) 20 (51)
Length - Inches (cm) 156 (396)
Lug Height - Inches (cm) 1.0 / (2.5)
Track tension sag in/cm
with 10 lbs/4.54kg placed
16 in/40cm ahead of rear
idler shaft
3/4” - 1” (1.9 - 2.5cm)
Front Suspension
Suspension Type Widetrak
Shocks Arvin Nitrex Gas Bag
IFS Spring Rate
lbs/in (N/mm)
105 (1.9)
Spring Pre-Load 3 x .135” Shims
Front Vertical Travel
Inches (cm)
7.25 (18.4)
Ski Center Distance
Inches (cm)
38 (96.5)
Camber Inches (cm) .82  0.72 (20.8  18.3)
Toe Out Inches (cm) 0 - 0.12 (0 - 0.31)
Rear Suspension
Suspension Type Widetrak Coupled Rail 156
Front Track Shock (FTS) Arvin Nitrex Gas Bag
FTS Spring Rate
lbs/in (N/mm)
181 (3.2)
Rear Track Shock (RTS) Arvin Nitrex Gas Bag
RTS Spring Rate
lbs/in (N/mm)
105 (1.9)
Cam Adjustable Pre-Load
Torsion Spring Diameter
Tail Angle
.468
74_
Rear Travel Inches (cm) 9 (22.9)
