2.26
9850043 R01 - 2017-2021 RANGER 500 / 570 Service Manual
© Copyright Polaris Inc.
7. Place a drain pan under the front gearcase drain
plug
w
.
8. Remove the drain plug and allow fluid to drain
completely.
9. Clean the drain plug magnetic surface.
10. Reinstall drain plug with a new O-ring and torque to
specification.
11. Add the recommended amount of fluid through the fill
hole. Maintain the fluid level even with the bottom
threads of the fill plug hole.
FLUID CAPACITY
Recommended Front Gearcase Fluid:
Polaris Demand Drive
(PN 2877922) (Quart)
Capacity: 6.7–7.6 oz. (200–225 ml)
12. Reinstall fill plug with a new O-ring and torque to
specification.
TORQUE
Front Gearcase Drain / Fill Plug:
10 ft-lbs (14 Nm)
13. Check for leaks. Dispose of used fluid properly.
MAINTENANCE
