Polaris RANGER 570 2020

9
9850043 R01 - 2017-2021 RANGER 500 / 570 Service Manual
© Copyright Polaris Inc.
9.7
REF
PART DESCRIPTION NOTES
q
MOUNT, EPAS
w
WHEEL, STEERING
e
SHAFT, STEERING, LOWER
r
SHAFT, STEERING, UPPER
t
ASM, GEAR BOX, STEERING
y
ASM, TILT STEERING
u
ASM, POWER STEERING
i
CAP, STEERING WHEEL
o
ASM, SHOCK, OIL LOCKING
a
BOLT
s
BOLT
d
BOLT 30 ft-lbs (41 Nm)
f
SCREW
g
BOLT
h
SCREW
j
BOLT
k
NUT
l
NUT
15 ft-lbs (21 Nm)
1(
NUT
40 ft-lbs (54 Nm)
2)
NUT
49 ft-lbs (66 Nm)
2!
NUT
65 ft-lbs (88 Nm)
2@
BUSHING, STEERING
2#
PIN, COTTER
2$
LOCTITE 271
STEERING / SUSPENSION
