1.80
9850043 R01 - 2017-2021 RANGER 500 / 570 Service Manual
© Copyright Polaris Inc.
SPN COMPONENT
FMI CONDITION CODE
5 Current Below Normal Or Open Circuit C163D
6 Current Above Normal Or Grounded Circuit C1B3D
7 Mechanical System Not Responding Or Out Of Adjustment C173D
8 Abnormal Frequency Or Pulse Width Or Period C133D
10 Abnormal Rate Of Change C183D
11 Root Cause Not Known C2429
14 Special Instructions C143D
20 Data Drifted High C193D
21 Data Drifted Low C1A3D
31 Condition Exists C1C3D
908
Wheel Speed Sensor (Rear Right)
2 Data Erratic, Intermittent Or Incorrect C1047
5 Current Below Normal Or Open Circuit C1647
6 Current Above Normal Or Grounded Circuit C1B47
7 Mechanical System Not Responding Or Out Of Adjustment C1747
10 Abnormal Rate Of Change C1847
20 Data Drifted High C1947
21 Data Drifted Low C1A47
31 Condition Exists C1C47
1071
Fan Relay Driver Circuit
3 Voltage Above Normal P1482
4 Voltage Below Normal P1483
5 Current Below Normal Or Open Circuit P1481
1127 Boost Pressure Sensor
0 Data Valid But Above Normal Operational Range P0234
2 Data Erratic, Intermittent Or Incorrect P0236
3 Voltage Above Normal P0238
4 Voltage Below Normal P0237
31 Condition Exists P1234
1268
Ignition Coil Primary Driver 1
(MAG)
3 Voltage Above Normal P1353
4 Voltage Below Normal P1361
5 Current Below Normal Or Open Circuit P1351
1269
Ignition Coil Primary Driver 2 (PTO)
3 Voltage Above Normal P1354
4 Voltage Below Normal P1362
5 Current Below Normal Or Open Circuit P1352
1321 Starter Enable Circuit
3 Voltage Above Normal P1617
4 Voltage Below Normal P1616
5 Current Below Normal Or Open Circuit P1615
1347
Fuel Pump Driver Circuit
3 Voltage Above Normal P0232
4 Voltage Below Normal P0231
5 Current Below Normal Or Open Circuit P0230
8 Abnormal Frequency Or Pulse Width Or Period P0233
1352
Knock Level Cylinder 1 (MAG)
0 Data Valid But Above Normal Operational Range P1336
16 Data Valid But Above Normal Operating Range P2336
1353
Knock Level Cylinder 2 (PTO)
0 Data Valid But Above Normal Operational Range P1337
16 Data Valid But Above Normal Operating Range P2337
1485
EFI Relay Control Circuit
3 Voltage Above Normal P0687
4 Voltage Below Normal P0686
5 Current Below Normal Or Open Circuit P0685
1557 Fan Driver 2
3 Voltage Above Normal P0694
4 Voltage Below Normal, Or Shorted To Low Source P0693
GENERAL INFORMATION
