7
9926595 R01 - 2015-2016 RANGER EV Service Manual
© Copyright Polaris Industries Inc.
7.3
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
ITEM
TORQUE
Front Caliper Mounting Bolts 28 ft-lb (38 Nm)
Rear Caliper Mounting Bolts 18 ft-lb (25 Nm)
Parking Brake Mounting Bolts 19 ft-lb (26 Nm)
Parking Brake Assembly Bolts 35 ft-lb (47 Nm)
Brake Line Flare Fittings 15 ft-lb (20 Nm)
Brake Line Banjo Bolts
(All)
15 ft-lb (20 Nm)
Front Brake Disc Bolts
18 ft-lb (24 Nm)
Rear Brake Disc Bolts
28 ft-lb (38 Nm)
Brake Switch
15 ft-lb (20 Nm)
Master Cylinder Clevis Nut 13 ft-lb (18 Nm)
SPECIAL TOOLS
PART NUMBER TOOL DESCRIPTION
2870975
MityVac® Pressure Test Tool
Dealers may order special tools through Polaris’ official
tool supplier, Bosch Automotive Service Solutions, by
phone at 1-800-345-2233 or on-line at http://polaris.
service-solutions.com/
BRAKE SYSTEM
