1.37
STANDARD BOLT TORQUE SPECIFICATION
BOLT SIZE
GRADE 2
FT. LBS. (NM)
GRADE 5
FT. LBS. (NM)
GRADE 8
FT. LBS. (NM)
1/4-20
5 (7) 8 (11) 12 (16)
1/4-28
6 (8) 10 (14) 14 (19)
5/16-18
11 (15) 17 (23) 25 (35)
5/16-24
12 (16) 19 (26) 29 (40)
3/8-16
20 (27) 30 (40) 45 (62)
3/8-24
23 (32) 35 (48) 50 (69)
7/16-14
30 (40) 50 (69) 70 (97)
7/16-20
35 (48) 55 (76) 80 (110)
1/2-13
50 (69) 75 (104) 110 (152)
1/2-20
55 (76) 90 (124) 120 (166)
METRIC BOLT TORQUE SPECIFICATION
BOLT
SIZE
GRADE
4.6 4.8 8.8 / 8.9 10.9 12.9
FT.- LBS. (NM) DRY THREADS
M3
0.3 (0.5) 0.5 (0.7) 1 (1.3) 1.5 (2) 1.5 (2)
M4
0.8 (1.1) 1 (1.5) 2 (3) 3 (4.5) 4 (5)
M5
1.5 (2.5) 2 (3) 4.5 (6) 6.5 (9) 7.5 (10)
M6
3 (4) 4 (5.5) 7.5 (10) 11 (15) 13 (18)
M8
7 (9.5) 10 (13) 18 (25) 26 (35) 33 (45)
M10
14 (19) 18 (25) 37 (50) 55 (75) 63 (85)
M12
26 (35) 33 (45) 63 (85) 97 (130) 111 (150)
M14
37 (50) 55 (75) 103 (140) 151 (205) 177 (240)
M16
59 (80) 85 (115) 159 (215) 232 (315) 273 (370)
M18
81 (110) 118 (160) 225 (305) 321 (435) 376 (510)
SAE TAP / DRILL SIZES
THREAD
SIZE DRILL SIZE
THREAD
SIZE DRILL SIZE
#0–80 3/64 1/2–13 27/64
#1–64
53
1/2–20 29/64
THREAD
SIZE DRILL SIZE
THREAD
SIZE DRILL SIZE
#1–72
53
9/16–12 31/64
#2–56
51
9/16–18 33/64
#2–64
50
5/8–11 17/32
GENERAL / BATTERY
