SPN COMPONENT
FMI CONDITION CODE
31 Condition Exists C1330
520253
ABS Solenoid (Rear or Right Rear
Out)
5 Current Below Normal Or Open Circuit C1025
31 Condition Exists C1332
520254
ABS Solenoid (Front or Front Left
In)
5 Current Below Normal Or Open Circuit C1026
31 Condition Exists C1326
520255
ABS Solenoid (Front or Front Left
Out)
5 Current Below Normal Or Open Circuit C1027
31 Condition Exists C1327
520256
ABS Solenoid (Front Right In)
5 Current Below Normal Or Open Circuit C1028
31 Condition Exists C1328
520257
ABS Solenoid (Front Right Out)
5 Current Below Normal Or Open Circuit C1029
31 Condition Exists C1329
520260 ABS Motor
3 Voltage Above Normal, Or Shorted To High Source C1020
4 Voltage Below Normal, Or Shorted To Low Source C1021
6 Current Above Normal Or Grounded Circuit C101E
7 Mechanical System Not Responding Or Out Of Adjustment C0020
8 Abnormal Frequency Or Pulse Width Or Period C101F
12 Bad Intelligent Device Or Component C101C
520262
ABS/Brake Controller Source
Voltage
0 Data Valid But Above Normal Operational Range - Most Severe Level C2422
1 Data Valid But Below Normal Operational Range - Most Severe Level C2421
3 Voltage Above Normal, Or Shorted To High Source C1039 / C1241
4 Voltage Below Normal, Or Shorted To Low Source C1038
520264 ABS/Brake Controller ECU
12 Bad Intelligent Device Or Component C1041
12 Bad Intelligent Device Or Component C1243
13 Out Of Calibration C1141
520265 ABS Module
7 Mechanical System Not Responding Or Out Of Adjustment C1042
520266
ABS Brake Switch (Front/Rear)
3 Voltage Above Normal, Or Shorted To High Source C1044
5 Current Below Normal Or Open Circuit C1043
520272
Glow Plug Relay Driver Circuit
3 Voltage Above Normal, Or Shorted To High Source P1384
4 Voltage Below Normal, Or Shorted To Low Source P1383
5 Current Below Normal Or Open Circuit P1385
520273
Fuel Pull Solenoid Relay Driver
Circuit (Low Side)
3 Voltage Above Normal, Or Shorted To High Source P125D
4 Voltage Below Normal, Or Shorted To Low Source P125C
5 Current Below Normal Or Open Circuit P125A
520275
Accelerator Position/Brake Position
Interaction
31 Condition Exists P150A / U1007
520276
Throttle Position Sensor (1 or 2
Indeterminable)
2 Data Erratic, Intermittent Or Incorrect P150C
12 Bad Intelligent Device Or Component P150B
520277
Throttle Body Control - Power
Stage
2 Data Erratic, Intermittent Or Incorrect P151A
3 Voltage Above Normal, Or Shorted To High Source P150D
4 Voltage Below Normal, Or Shorted To Low Source P150E
8 Abnormal Frequency Or Pulse Width Or Period P151B
