9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
1.41
SPN COMPONENT
FMI CONDITION CODE
17 Data Valid But Below Normal Operating Range - Least Severe Level P0171
520205 Fuel Correction Rear
15 Data Valid But Above Normal Operating Range - Least Severe Level P0175
17 Data Valid But Below Normal Operating Range - Least Severe Level P0174
520206 Reverse Alarm
2 Data Erratic, Intermittent Or Incorrect P1684
3 Voltage Above Normal, Or Shorted To High Source P1682
4 Voltage Below Normal, Or Shorted To Low Source P1683
5 Current Below Normal Or Open Circuit P1681
520207 All Wheel Drive Control Circuit
3 Voltage Above Normal, Or Shorted To High Source P1835
4 Voltage Below Normal, Or Shorted To Low Source P1834
5 Current Below Normal Or Open Circuit P1836
520208
Chassis Relay
3 Voltage Above Normal, Or Shorted To High Source P1614
4 Voltage Below Normal, Or Shorted To Low Source P1613
5 Current Below Normal Or Open Circuit P1611
520211
Idle Speed
3 Voltage Above Normal, Or Shorted To High Source P0507
4 Voltage Below Normal, Or Shorted To Low Source P0506
520219
Accessory Relay
3 Voltage Above Normal, Or Shorted To High Source P1647
4 Voltage Below Normal, Or Shorted To Low Source P1645
5 Current Below Normal Or Open Circuit P1646
520220
Battery Charge Relay
3 Voltage Above Normal, Or Shorted To High Source P163D
4 Voltage Below Normal, Or Shorted To Low Source P163A
5 Current Below Normal Or Open Circuit P163C
520221
Steering Over Current Shut Down
6 Current Above Normal Or Grounded Circuit C1050
12 Bad Intelligent Device Or Component C102E
520222
Steering Excessive Current Error
6 Current Above Normal Or Grounded Circuit C1051
520223
Steering Torque Partial Failure
31 Condition Exists C1052
520224
Steering Torque Full Failure
31 Condition Exists C1053
520225
EPS Inverter Temperature
0 Data Valid But Above Normal Operational Range - Most Severe Level C1055
12 Bad Intelligent Device Or Component C102F
16 Data Valid But Above Normal Operating Range - Moderately Severe
Level
C1054
520226
EPS Communications Receive
Data Error
2 Data Erratic, Intermittent Or Incorrect U0100
31 Condition Exists C1067
520227
EPS CAN Communications
Transmit Error
2 Data Erratic, Intermittent Or Incorrect U1100
520228 Position Encoder Error
11 Root Cause Not Known C1065
12 Bad Intelligent Device Or Component C106A
31 Condition Exists C106B
520229 Software Error
12 Bad Intelligent Device Or Component C1070
31 Condition Exists C106F
520230 IC CAN Communication with EPS
31 Condition Exists U0131
520231 EPS Power Save Condition
31 Condition Exists C1071
520252
ABS Solenoid (Rear or Right Rear
In)
5 Current Below Normal Or Open Circuit C1024
GENERAL INFORMATION
1
