4.4 I Replacing the brushes
Are the brushes worn?
• Replace the brushes if the wear indicators are similar to example :
Remove the worn brushes
• Remove the tabs from the holes inside which they are fastened, then remove the brushes.
Posi on the new brushes.
• Fit the side without tabs under the brush holder (see  gure
).
• Roll the brush around its support, slide the tabs into the a achment holes and pull on the end of each tab un l its
edge passes through the slit (see  gure
).
• Cut the tabs using a pair of scissors for them to be level with the other blades (see  gure ).
